Eleven documents, two utilities, one command

The system picks the documents, not the person

Each utility asks for a different set of documents to connect a solar plant: CEMIG asks for one, Equatorial Goiás asks for another. The operator only fills in the customer's data. The system identifies the utility and builds on its own the set that utility requires.

What I ruled out: letting the person tick, on a list of eleven documents, which ones go into the request. To get it right, they would have to remember each utility's rule in the middle of repetitive work, which is exactly when people forget.

A wrong attachment is refused, not flagged later

When the robot detects that an attachment came out wrong, it removes the reference and leaves the item as pending, instead of delivering the file.

Why: a missing attachment shows up on the pending list and someone adds it before sending. A wrong attachment reaches the utility, and comes back weeks later. The two cost different amounts.

The robot also refuses to tick a connection option that the utility's own access opinion declares unfeasible, and refuses to generate the term without the original project.

Access opinion data is read from the PDF, never typed

The numbers from the reverse power flow study come in read from the PDF of the access opinion issued by the utility.

What I ruled out: a field in the form for the operator to copy the value. Retyping a number from an official document is the cheapest source of error there is, and the error only shows up when the process comes back.

When the second utility was added, the first one came out identical byte for byte

Parameterizing a generator that already works is where you break what was right. The safeguard was to freeze the result: four baselines compare the finished artifact, not the code.

The technical description is checked with the text in order. The utility's attachment is checked member by member inside the compressed file, because the checksum of the .xlsx changes on its own: the format records the date and time of compression.

What I ruled out: relying on unit tests of the changed functions. They pass while the delivered document shifts.

Updating a baseline is manual on purpose: if it were automatic, it would record the defect as if it were the new correct result.

A document declares which code is live

The project has 121 scripts. More than once I edited a file, ran the process and the output came out the same, because the file was not on the execution path.

The fix was to write a document that lists, stage by stage, which file is called and by which function. Its first line says to read it before touching anything.

Why: losing time like that once is distraction. Twice is a sign that the project was not telling the truth about itself.
